Filament Spectrum Nylon PA6 Low Warp CF15S 1.75mm BK 1kg
Filament Spectrum PA6 Low Warp CF15S
Low shrinkage and high strength paired up with the advantages of carbon fibres
Polyamide 6 is one of the strongest materials used in desktop 3D printing technology. It combines mechanical strength,...
Filament Spectrum Nylon PA6 Low Warp CF15S 1.75mm BK 1kg
Spectrum color name: Black
Choose another$65.99 USD
Description
Filament Spectrum PA6 Low Warp CF15S
Low shrinkage and high strength paired up with the advantages of carbon fibres
Polyamide 6 is one of the strongest materials used in desktop 3D printing technology. It combines mechanical strength, stiffness, vibration damping ability and abrasion resistance unmatched by any other types of filaments. It can successfully add chemical resistance and the ability to operate continuously at high temperatures to its wide range of properties.
With the introduction of heat-stabilised, carbon fibre-filled Spectrum PA6 Low Warp CF15S composite material, we set out to raise the bar for nylon filaments even higher. Spectrum PA6 Low Warp CF15S is a true heavy-duty specialist. The "LowWarp" moel is characterised by extra mixture content designed to improve the flow during extrusion of the material - and thus improved adhesion of the material particles. With the use of 15% carbon fibres, the stiffness goes up over two times and tensile strength improves (up to 120 MPa). In addition, Spectrum PA6 Low Warp CF15S has a higher HDT thermal resistance of 180°C (0.45MPa), compared to the unfilled version. The fibre content reduces the shrinkage, which is common or most high-temperature materials, making the printing process much easier and giving prints an aesthetically pleasing "carbon-like" look.
Spectrum PA6 Low Warp CF15S is the best choice for printing functional models that require high rigidity and continuous high-temperature and chemical resistance. It can easily be used in the automotive, aerospace and modelling industries.
Key features:
- 15% carbon fibres
- two-fold increase in rigidness compared to non-modified polyamid
- high mechanical properties and abrasion resistance
- excellent chemical resistance
- HDT thermal resistance - 180°C (0.45MPa)
- printable on desktop devices without a heated chamber
- matt, carbonised print surface
- perfect bonding of the layers
Applications:
- functional prototype,
- production tooling
- working components of tools and machinery - rotors, gears
- guides, gear racks, guide rollers
- manufaturing protective rings and plates with increased chemical and corrosion resistance
Packaging
Filament is reeled on the neat, transparent spool. Each spool contains information on the type of material, diameter and recommended printing temperature. Filament is vacuum-packed with a moisture absorber. Whole product packed in the original, folied Spectrum Filaments packaging.
Specification
General information
Specification
Technical data
How to print?
Spool dimensions
250
44
140
52
120
Plastic
Transparent
250
44
140
52
80
Cardboard
-
500
55
200
52
240
Plastic
Transparent
750
55
200
52
240
Plastic
Transparent
1000
67
200
52
260
Plastic
Transparent
1000
67
200
52
180
Cardboard
-
2000
100
300
52
600
Plastic
Black
2000
100
300
52
420
Cardboard
-
4500
100
350
52
780
Plastic
Black
8000
167
355
36
1020
Plastic
Black
Each spool is sealed. We recommend storing filaments in a cool (15-25°C) and dry place.
Reviews
Description
Filament Spectrum PA6 Low Warp CF15S
Low shrinkage and high strength paired up with the advantages of carbon fibres
Polyamide 6 is one of the strongest materials used in desktop 3D printing technology. It combines mechanical strength, stiffness, vibration damping ability and abrasion resistance unmatched by any other types of filaments. It can successfully add chemical resistance and the ability to operate continuously at high temperatures to its wide range of properties.
With the introduction of heat-stabilised, carbon fibre-filled Spectrum PA6 Low Warp CF15S composite material, we set out to raise the bar for nylon filaments even higher. Spectrum PA6 Low Warp CF15S is a true heavy-duty specialist. The "LowWarp" moel is characterised by extra mixture content designed to improve the flow during extrusion of the material - and thus improved adhesion of the material particles. With the use of 15% carbon fibres, the stiffness goes up over two times and tensile strength improves (up to 120 MPa). In addition, Spectrum PA6 Low Warp CF15S has a higher HDT thermal resistance of 180°C (0.45MPa), compared to the unfilled version. The fibre content reduces the shrinkage, which is common or most high-temperature materials, making the printing process much easier and giving prints an aesthetically pleasing "carbon-like" look.
Spectrum PA6 Low Warp CF15S is the best choice for printing functional models that require high rigidity and continuous high-temperature and chemical resistance. It can easily be used in the automotive, aerospace and modelling industries.
Key features:
- 15% carbon fibres
- two-fold increase in rigidness compared to non-modified polyamid
- high mechanical properties and abrasion resistance
- excellent chemical resistance
- HDT thermal resistance - 180°C (0.45MPa)
- printable on desktop devices without a heated chamber
- matt, carbonised print surface
- perfect bonding of the layers
Applications:
- functional prototype,
- production tooling
- working components of tools and machinery - rotors, gears
- guides, gear racks, guide rollers
- manufaturing protective rings and plates with increased chemical and corrosion resistance
Packaging
Filament is reeled on the neat, transparent spool. Each spool contains information on the type of material, diameter and recommended printing temperature. Filament is vacuum-packed with a moisture absorber. Whole product packed in the original, folied Spectrum Filaments packaging.
Specification
General information
Specification
Technical data
How to print?
Spool dimensions
| Content [g] | Width [mm] | Outer diameter [mm] | Inner diameter [mm] | Weight empty [g] | Material | Spool color |
|---|---|---|---|---|---|---|
| 250 | 44 | 140 | 52 | 120 | Plastic | Transparent |
| 250 | 44 | 140 | 52 | 80 | Cardboard | - |
| 500 | 55 | 200 | 52 | 240 | Plastic | Transparent |
| 750 | 55 | 200 | 52 | 240 | Plastic | Transparent |
| 1000 | 67 | 200 | 52 | 260 | Plastic | Transparent |
| 1000 | 67 | 200 | 52 | 180 | Cardboard | - |
| 2000 | 100 | 300 | 52 | 600 | Plastic | Black |
| 2000 | 100 | 300 | 52 | 420 | Cardboard | - |
| 4500 | 100 | 350 | 52 | 780 | Plastic | Black |
| 8000 | 167 | 355 | 36 | 1020 | Plastic | Black |
Each spool is sealed. We recommend storing filaments in a cool (15-25°C) and dry place.
